Specifications

Model Performance
Model S3-Q12JA3FB
Cooling Capacity 3520W
Cooling Capacity BTU/Hr 12011
Cooling Capacity Min Max 600-3650W
EER COP 11.44
Air Circulation Indoor Outdoor 423/989 CFM
Noise Level Indoor 41/36/27/22 dB
Noise Level Outdoor 51 dB

Electrical
Compressor Type Gas Dual Rotary / R-32
Power Supply 1/220-240/50
Power Input Cooling 1050W
Power Input Min Max 185-1330W

Interconnecting Pipe
Liquid Side 6.35mm (1/4)
Gas Side 9.52mm (1/2)

Highlights
Cooling Capacity Range 520-3850W
Compressor Dual Rotary / R-32
Power Supply 220-240V Single 50Hz
Air Circulation In Out 425/989 CFM
Noise Level Indoor 21 dB
Super Convertible 5-in-1 Cooling Yes
Panel Display Magic Display
Filter Type HD Filter with Antivirus Protection
Auto Air Swing Up Down Yes
Auto Air Swing Left Right Yes
Dual Inverter Yes
100 Percent Copper Yes
Ocean Black Fin Yes
Ocean Black Protection Yes
High Capacity Mode Yes
Wi-Fi Yes
Monsoon Comfort Yes
Low Gas Detection Yes
Smart Diagnosis System Yes
Comfort Air Yes
Ez Clean Filter Yes
Stabilizer Free Operation Yes
Cools at 52C Yes
Auto Clean Yes
Sleep Mode Yes

Dimensions
Indoor Unit 837 x 308 x 189 mm
Outdoor Unit 717 x 495 x 230 mm
Net Weight Indoor 8.4 kg
Net Weight Outdoor 24.5 kg

Terms & Conditions

Free installation up to 5m piping from indoor to outdoor unit
Extra piping will be charged separately
1 Year Comprehensive Warranty and 10 Year Compressor Warranty (with service agreement from 2nd year)
Specifications may change without prior notice
Noise levels measured in Anechoic Chamber
Free installation valid only within 1 year of purchase
If existing piping is used, any resulting issues are not covered under warranty
